Variants

1814FG | Washbasin faucet with washing machine valve

Oras Vega

EAN code
6414150102851

Active markets
FIN, EST, LVA, LTU

Oras Vega

A faucet that began saving water in 1976. That year, we created our first water and energy-saving single-lever faucet, which was the direct progenitor of Oras Vega. In developing the Oras Vega series, we made full use of our decades of experience and the highly functional solutions we have refined over the years.

Discover All products

Features

Aerator Standard aerator
Connection Flexible inlet pipes
Dishwasher valve Mechanic stop valve for external equipment
Hand shower Bidetta hand shower
Lever/Handle Eco feature for water flow, Hot/Cold symbols, Safety feature for water temperature, Single operating lever/handle
Mechanical parts ø 40 mm ceramic cartridge for flow and temperature control
Mounting holes 1 hole
Number of spray functions 1 spray function
Shower parts Hand shower, Shower holder, Shower hose (1500 mm)
Advanced features 3S-installation system for safe and simple mounting
Spout Swivel spout
Color Chrome
Temperature Limitation option for maximum temperature and flow-rate

Flow attributes

Eco-flow at 300 kPa 0.12 l/s
Flow-rate at 300 kPa 0.14 l/s
Pressure loss with flow (0.1 l/s) 160 kPa

Technical properties

Connection size G3/8
Hot water supply max. +70°C
Material Brass
Projection 133 mm
Working pressure 50 - 1000 kPa

Regulations

EN standard EN 817
Noise class I (ISO 3822)

Sustainability

ItemEPDA1 10,62
ItemEPDA1A2A3 12,13
ItemEPDA2 0,51
ItemEPDA3 1,00
ItemEPDA4 0,34
ItemEPDB7 2224,80
ItemEPDC2 0,02
ItemEPDC3 0,03
ItemEPDC4 0,09
ItemEPDD -8,63

SP1814G Washbasin faucet with washing machine valve

Ask pricing from your local retailers.

	Spare parts		Code	Spare part guide
01		Lever (Chrome)	1000935V
02		Limiter	1004821V
03		Covering cap (Chrome)	602589V
04		Tightening nut, M42x1.5, SW 38	158726
05		Cartridge	158890	Download
06		Spout, L=132 (Chrome)	602520V
07		Spout overturning stopper, 120°	1001406/10
07		Spout overturning stopper, 40°-80°	1002207/10	Download
08		Fixing screw, M8x1, L=130	1000780V
09		Fixing set	602610V	Download
10		Aerator, M24x1 STD HC A (Chrome)	232211
11		Bearing ring	601097/10
12		X-sealing set	158735	Download
13		Bearing ring	159423/10
14		Headpart, G1/2	602600V
15		Handle for washing machine valve (Chrome)	1005697V
16		Bottom seal	1002371V
17		Supporting plate, 100x60mm	158825
